Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use

Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use

  • Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use
  • Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use
  • Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use
Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use
Product Details:
Place of Origin: China
Brand Name: FAMOUS
Certification: CE,ISO9001,SASO,SGS
Model Number: None
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD80-200 per Square meter
Packaging Details: Standard seaworthy packing
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 1000 sets per month
Contact Now
Detailed Product Description
Door Frames: Aluminum Alloy Frame, Steel Metal Frames,etc Type: Vertical Lifting, Up Rising, Etc
Color: Clea,Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized Surface Treatment: Normal Paint,galvanized ,or Customized,etc
Application: Car Showroom, Industrial Warehouse,shopping Mall,etc Size: Customized As Order
Wind Resistance: 25m/s ( Wind Scale 10) Certification: CE/ ISO 9001
Power Supply: 1-phase-220v, 3phase-380v Core Materials: Clear Tempered Glass,etc

Aluminum Exterior Frame Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use



 Description


    Fully Glazed Industrial Doors Optimise light inlet and product visibility with the ultra-attractive . The fully-glazed overhead sectional industrial door is designed for use in facilities looking to maximise natural light, increase visibility of products and ensure personnel can see clearly through doors. Ideal for car showrooms and dealerships, fire stations, or any facility where maximum light inlet and/or product exposure is desirable.The aluminum frames of the fully glazed doors are anodized or painted to preference. Panels are single, double or reinforced triple glazing, presenting a modern, attractive and unique appearance in customer facing entrances.

    Improve natural light inlet and aesthetics without compromising stability with attractive, glazed overhead sectional industrial doors. Glazed overhead sectional doors are an industrial door with a difference; visually appealing and highly practical the glazed sections improve natural light inlet and visibility. The natural choice where product demonstration is a priority, the glazing arrangement benefits from the added stability of a 44mm thick aluminium tubular frame, which makes the "Nature Sunlight" a practical door system for entrances where industrial and/or commercial traffic must pass. Windows arranged in a 'grid' formation can be complemented by insulated solid panels to further enhance stability. Although all rows can be glazed, the most common arrangement of the "Nature Sunlight" sees the bottom row 'infilled', making it both easier to clean and more resistant to scratches and general wear and tear.



Specification:



Items

Glass Facade Door/Fully Glazed Door

Measurement

Customized as order

Type

Large French Doors, Swing door,Casement/Sliding/Folding,etc









Materials

Aluminum profile

Series

55/65/68/72/75/80/83/100/120etc.

Construction

Thermal Break/Non- Thermal Break

thickness

1.4/1.6/1.8/2.0mm

Surface treatment

Powder coated/anodized/PVDF/wood grain transfer / Electrophoresis, etc.

Color

White/black/grey/brown/silver/wood color etc. can be customized.

Glass

Glass type

Tempered glass/laminated glass/coated glass/filmed glass/low-e glass/reflective glass /insulated glass etc.

Glazing

Single/double/triple

thickness

Single: 5/6/8/10/12mm

Double:5+5/6+6mm laminated glass/5+12A+5/6+12A+6mm insulated glass

Color

Clear/frosted/tinted (grey, blue, light green, bronze etc.) can be customized.

Hardware

Brand

King Long/HOPO/as per your required.

Screens

All the opened window and doors can be match the screens

Stainless steel security mesh

Nylon fly screen

Retractable & invisible fly screen

Others

Packages

Foam/bubble +plywood



Delivery

20-30 days after confirmed the order





Features:


Standard size up to (W x H) : 5500 x 4250 mm
Frame thickness: 44 mm
Windows: W < 3300 mm: 1 pane, W > 3300 mm: 2 panes
Pass-door: not available
Access and Automation: optional
Wind load, EN 12424 [2]: class 3: W < 3300, class 2: W > 3300
Thermal transmittance, EN 12428: 6 W/m2K
Water penetration, EN 12425: class 3
Air permeability, EN 12426: class 2
Other sizes on request
Higher wind load classificationon request





Advantages:



Maximum Glazing - Minimal Frame
Glazed sections up to 3.3 meters in width are available with the TOPSKY Fully Glazed industrial overhead sectional door. Owing to the design, no 'middle transom' is required for panes of up to 2.6m in length as the the frame is self supporting. Designers and architects are afforded the opportunity to create a clean, glass-like aesthetic for their working entrances in order to match a fully glazed facade.



Maximising Space
The overhead sectional door slides up under the roof when opened, maximising free space around the door opening. The overhead arrangement leaves entrances open and completely clear for product placement, or simply freeing up additional useable space.



Glazing arrangement
The number of rows and columns of the "Nature Sunlight" is based entirely on the width and height of the door, which is divided equally creating the grid arrangement.



Wide range of opening
As with any overhead sectional door, the "Nature Sunlight" opens vertically into the roof/ceiling, maximising useable space in and around the opening. Running on tracks, the door rolls up and over. Track arrangements are decided by factoring the available space directly above the door opening and immediately inside the facility.



Safety Compliance
The TOPSKY fully-glazed overhead sectional door is designed to meet all operational and safety requirements in the European Directives and the standards issued by the European Standardization Committee, CEN.



Aluminum Exterior Panel Folding Glass Facade Doors Sensor Glazing Doors For Car Showroom Use 0
