| Place of Origin: | China |
| Brand Name: | FAMOUS |
| Certification: | CE,ISO9001,SASO,SGS |
| Model Number: | None |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD80-200 per Square meter |
| Packaging Details: | Standard seaworthy packing |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 sets per month |
| Door Frames: | Galvanized Steel , 304stainless Steel,etc | Type: | Acoordion Folding Door, Rolling Door,shutter Door,etc |
|---|---|---|---|
| Color: | Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized | Surface Treatment: | Normal Paint,galvanized ,etc |
| Application: | Food Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc | Surface: | Painted Finish, Galvanized Treatment,etc |
| Size: | Customized As Order | Wind Resistance: | 25m/s ( Wind Scale 10) |
| Certification: | CE/ ISO 9001 | Power Supply: | 1-phase-220v, 3phase-380v |
| Core Materials: | Polyurethane Core, PVC Plastic Fabric,etc |
Description:
TOPSKY hinged cold rooms and freezer doors can be deployed from temperatures of -40° C to normal operating temperatures. Whether as cold storage, freezer or even shock freezer rooms. The varying insulation gauges, from 60 to 140 mm, are perfectly matched to the required cold-store temperature. The outstanding PUR/PU insulation and sealing properties of these doors make a contribution to the energy-saving operation of cold store and freezer rooms.
However, TOPSKY hinged cold rooms and freezer doors are equally suited for use in work and warehouse areas. Thanks to the variety of door sizes and range of frame constructions, they perfectly fulfil their purpose and the specific installation scenario. The door surfaces meet strict hygiene regulations and are mostly made of galvanised or painted sheet steel or stainless steel. The best insulating isothermal doors on the market for frozen and cold rooms, cold tunnels, quick freezing tunnels. Perfect airtightly closing doors with a wide choice of framework types, finishes and optional accessories. These doors are very user-friendly, durable, reliable and meet the most stringent requirements of the food processing industry .
Specifications:
| Item Name | Insulated hinged doors |
| Dimension | Width (m)*Height (m) According to client's requirement . |
| Panel density | 38-42kg/m3, fire retardant |
| Door Frame | Galvanized steel frame,stainless steel frames,or other type,etc |
| Panel thickness | 50mm,75mm,100mm,150mm,200mm,etc |
| Steel cover | stuccom embossed aluminum,painted galvanized steel,stainless steel,PVC stell,etc |
| Panel connection | Inserted panel type, use insert to assemble and disassemble |
| Type of door | hinge door, convex door, sliding door |
| Temp.of room | -45~+20 degree, optional |
| Purpose of cold room | fruit,vegetable,flower,fresh/frozen meat,etc |
| Fittings | all necessary fittings are included, optional |
| Place to assemble | indoor/out door(concrete construction building/steel construction building) |
Features:
1.PU sandwich panel cold room door
2.Good heat preservation performance
3.Thickness:100m/120mm/150mm/200mm
4. classification: manual or electric slide door, fully-burried door, half or fully-burried double door, half burried with small door, and other types according to customers.
5.Easy to install
Key benefits:
Super insulating door panels
For cold and frozen applications
Default double sealing rubbers
100% damp proof and hermetic closing
Rising and adjustable hinges
Functional adjustable door fittings
Extensive choice of frames, finishing and colours
Various options for all kinds of applications
Super quality at the best price
Main Applications: Hotels, hospitals, blood banks, poultry slaughter and processing, aquaculture and processing, mushroom cultivation, agricultural product processing, dairy production, pharmaceutical processing and logistics, beverage production and processing, beer production and cooling, large-scale logistics storage, chemical product cooling, leather manufacturing, injection molding, machine cooling, steel cooling, communication equipment, ship manufacturing and more.
