UL Standards Steel Fire Rated Single Swing Door

UL Standards Steel Fire Rated Single Swing Door

  • UL Standards Steel Fire Rated Single Swing Door
  • UL Standards Steel Fire Rated Single Swing Door
  • UL Standards Steel Fire Rated Single Swing Door
UL Standards Steel Fire Rated Single Swing Door
Product Details:
Place of Origin: China
Brand Name: FAMOUS
Certification: CE,ISO9001,SASO,SGS
Model Number: None
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD500-1000 per Set
Packaging Details: Standard seaworthy packing
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 1000 sets per month
Contact Now
Detailed Product Description
Door Material: Steel Core Material: Steel Plate
Type: Steel Fire Rated Doors Color: Customized
Surface Sheet: Galvanized Steel Application: Villa /Apartment/ Hotel/shopping Mall/office
Surface: Painted Size: Standard
Fire Resistance: 3 Hours

UL Standards Steel Fire Rated Single Swing Door

Fire rated door is a door that can meet the requirements of fire resistance stability,

integrity and thermal insulation within a certain period of time.
It is a fire partition with certain fire resistance, such as fire compartments, evacuation stairwells, vertical shafts, etc.

In addition to the function of ordinary doors, fire doors also have the function of preventing the spread of fire and smoke,

which can prevent the spread of fire within a certain period of time and ensure the evacuation of people.



Fire doors are generally located in the following locations:
(1) Close the evacuation stairs, leading to the aisle; close the elevator room, leading to the front room and the door leading to the aisle from the front room.
(2) Inspection doors for vertical pipeline wells such as cable wells, pipeline wells, flue exhaust ducts, and garbage ducts.
(3) Divide the fire compartment, and control the fire wall and the door on the fire partition wall set up in the building area of the compartment. When it is difficult to set up a fire wall or a fire door in a building, a fire shutter door should be used instead, and it must be protected by a water curtain.

Filler Material Honey Core, Mineral rock wool, polyurethane core.
Fire rated time 1 hour up to 3 hours.
Min. Thickness 45mm
Size Maximum size is (2530x2530mm)
Door leaf sheet 22 Ga. - 18 Ga. (0.8/1.0/1.2 mm)galvanized steel/cold roll steel
Door frame sheet 16 Ga. - 14 Ga. (1.5mm-2.0mm). cold roll steel/galvanized steel
Surface finish Door leaf and frame powder coated finish.
Frame depth 115mm - 240mm
Opening direction Swing Inward / Outward
Color RAL color system, could be customized as well.
Accessories Lock,handle,hinges,door closer,panic bar and other as requested.
Vision Panel With or without as requested.
Lite Frame UL listed lite frame
Louver With or without as requested.
Feature Fire proof and thermal insulation.
Application building project, business, home decoration(Office, hotel, church, home etc.)
Package Inside:PE paper , Outside: double layers carton box and wooden pallets.



UL Standards Steel Fire Rated Single Swing Door 0

UL Standards Steel Fire Rated Single Swing Door 1

UL Standards Steel Fire Rated Single Swing Door 2
