| Place of Origin: | China |
| Brand Name: | FAMOUS |
| Certification: | CE,ISO9001,SASO,SGS |
| Model Number: | None |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD80-200 per Square meter |
| Packaging Details: | Standard seaworthy packing |
| Delivery Time: | 15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 sets per month |
| Door Frames: | Galvanized Steel , 304stainless Steel,etc | Type: | Lifting Door, High Speed Rising Door,etc |
|---|---|---|---|
| Color: | Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized | Surface Treatment: | Normal Paint,galvanized ,etc |
| Application: | Food Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc | Surface: | Painted Finish, Galvanized Treatment,etc |
| Size: | Customized As Order | Wind Resistance: | 25m/s ( Wind Scale 10) |
| Certification: | CE/ ISO 9001 | Power Supply: | 1-phase-220v, 3phase-380v |
| Core Materials: | PVC Plastic Fabric |
Description:
High Speed PVC Door is widely used in modern factories and warehouses. It can run in very high speed (up to 2.5m/s)and frequency (up to 2000 times/day), very fit for areas with heavy traffic. Air flow through the door is reduced obviously, to protect indoor environment. Automatic running is realized with programmed control system and sensors. Automatic and high performance speed door is also the solution to the environment which needs prevent dust and clean easily in the busy passageway area with high clearness demands,strong wind- pressure,especially in the food,pharmacy, and fine machining industry.
Specifications:
| PVC High Speed Rolling Door | |
| Size | 6000mm( W)*8000( H),actual size: cutomized as order; |
| Speed (frequency control system) |
opening 1.5m/s (adjustable); closing 1.2m/s (adjustable) |
| Material | 1. 1.5mm coating galvanized steel; 2.0mm aluminum alloy; 2.0mm 304 stainless steel, food grade , chemical proof ; 2. 0.8mm/1.2mm/1.5mm PVC plastic fabric; |
| Color | Blue,Yellow,Red,Grey,White,Full-clear,etc |
| Safety Device | photoelectricity / airbag / bollards |
| Opening Device | Button / radar / remote control / rocker / geomagnetism / pull switch / swipe fingerprint machine, etc. |
| Control Systerm | Domestic or Foreign motor brands ( PLC, transducer, switching power supply, breaker, etc.) |
| Motor(power supply) | 380V (3phase)or 220V(1phase )/50HZ 0.75KW/ 1.1KW/1.5KW |
| Main Features | 1. Box cover and track are made of high strength aluminum alloy that is treated by oxidation, both beautiful and durable; 2. New and beautiful aluminum alloy intergral bottom beam, whose bottom can be installed with safety rubber protection device; 3. Removeable windproof aluminum alloy rib makes the curtain replacement more convenient; 4. The system will automatically turn off the power when the door hasn't run for 30 minutes, the system will restart within 10 milliseconds once there is a new signal. It can save 30%electricity compared to the traditional system; 5. With most advanced control system which has many advantages, such as high speed, high stability, high precision, and intellignent . |
Production processes:
Features:
1. High intensity fire insulation, sound insulation, spray the surface corrosion.
2. Install tamper device, effectively protect your property.
3. Bearing pulleys easy adjustment to ensure smooth lifting process without noise
4. Double security guards, fall protection + anti-fracture "
5. Using frequency: 2000 times a day
6. Convenient to operate
7. Visible window available
PVC rapid action rolling door / roll up door
1. For door decorating, Accessories according to the European standard
2. Manual or remote operation available
3. Middle, exterior and interior installation
Advantages:
Safe: This kind of door use infrared sensor and airbag which can ensure huaman's safety. The door will stop closing quickly when someone go across.
Long lifetime: The cover box use 2.0mm high quality galvanized steel which can protect door from bad environment so that the can work long time.
Faster: This kind of door use imported SEW motor so that the open speed can reach 2.5/s max and close speed can reach 1.2m/s.
Easy to clean: The curtain use imported PVC fabric which can clean easily.
Save energy: The system will turn off the power automatically when the door hasn't work for 30 minutes, and the system will restart within 10 milliseconds once there is a new signal.
