Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby

We are proud to announce the 6th years cooperation with Topsky Doors. Congratulations to their new height in the foreign markets!

—— John Fexwell

Topsky is a great partner. they can always offer satisfied and instant installation guidance ranging from manual, video, to technician directly arriving in site. we are really happy with that and wish them a prospect future!

—— Francisco Du.Du.

I'm Online Chat Now

Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby

Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby
Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby

Large Image :  Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby

Product Details:

Place of Origin: China
Brand Name: FAMOUS
Certification: CE,ISO9001,SASO,SGS
Model Number: None

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD80-200 per Square meter
Packaging Details: Standard seaworthy packing
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 1000 sets per month
Detailed Product Description
Door Frames: Aluminum Alloy Frame, Steel Metal Frames,etc Type: Swing Door, Sliding Door, Vertical Lifting, Up Rising, Etc
Color: Clear,Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized Surface Treatment: Normal Paint,galvanized ,or Customized,etc
Application: Car Showroom, Industrial Warehouse,shopping Mall,etc Size: Customized As Order
Wind Resistance: 25m/s ( Wind Scale 10) Certification: CE/ ISO 9001
Power Supply: 1-phase-220v, 3phase-380v Core Materials: Clear Tempered Glass,etc

Modern Electrical Revoling Glass Facade Doors For Hotel or Shopping Mall Lobby

Standard revolving glass facade doors ensure building entrances are functional, draught-excluding and soundproof. The flexible design and multitude of options allow for individual solutions varying in function, appearance and size. The standard revolving door can be operated manually, semi-automatically by activating the Push&Go function or automatically by activating the radar sensors, as required.
The drum walls may be designed with glass but also with heat-insulated panels of sheet metal. Regardless of the option chosen, user safety is always the top priority.



Technical Specification:
Power: 220V, 50-60Hz
Motor Power: 180W
Light Power: 40W
Door Speed: 1-4 circle/m
Rotational Noise:<42db
Door Torque: <2nm





Size
inner diameter

outer

diameter

Canopy Height door Wing Height Entrance & Exit Width
3-Wing 4-Wing
3000 3180 300 2200 1400 2030
3200 3380 300 2200 1500 2170
3400 3580 300 2200 1600 2310
3600 3780 300 2200 1700 2450
3800 3980 300 2200 1800 2590
4000 4180 300 2200 1900 2730
4200 4380 300 2200 2000 2870
4800 4980 300 2200 2300 3050
unit:mm



Automatic revolving door,Automatic door functions:
Normal functions:
1. Responsive rotation: The infrared motion sensor perceives the moving objects( or signals), the door rotates automatically.
2. Anti-clamp: The anti-clamp sensor( infrared or extrusive) can avoid the door injuring the person passing by.
3. Emergency button: Push the button on the post, the door will stop immediately.
4. Lower speed: Push the button on the post, the door will rotate slowly.
5. Automatically display of functional status and malfunction: The screen on the post can display the code of doors operational state and the malfunction information.
6. Speed adjustment: Frequency conversion technology can adjust the speed rotate steadily.
7. High-efficiency seal: The high-quality brush keeps draught, cold and noise outside.
Optional functions:
1. UPS: In the event of a power failure, the urgency electric power system can supply power to keep the door rotate.
2. Fingerprint identification: The fingerprint system can limit the qualifications of passenger to improve safe performance.
3. Fire central control: The fire control signal of building links to the door, the door unlock or switch to the urgency evacuation mode automatically when the fire alarm rise.
4. Customized products according to customers requirements.



Advantages:
Easy operation
Large panes of unobstructed glass
Flexible room arrangements with more usable space
Sliding screens are available
Design flexibility


Features:
3" stiles and rails provide a modern look that maximizes your view
Elegant harp-shaped handle and two-point lock system provide security
Ultrex sill withstands traffic and seasonal changes, so the door slides smoothly and easily
Design options such as four-panel patio doors are available
Optional top-hung screen are adjustable
Available up to 16 feet in width
Optional low-profile, high-performance sill is ideal for Universal Design
