|Place of Origin:||China|
|Minimum Order Quantity:||1 set|
|Price:||USD80-200 per Square meter|
|Packaging Details:||Standard seaworthy packing|
|Delivery Time:||15 days|
|Payment Terms:||L/C, T/T|
|Supply Ability:||1000 sets per month|
|Door Frames:||Steel , Aluminum,stainless Steel,etc||Type:||Sliding Door, Front Gates,etc|
|Color:||Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized||Surface Treatment:||Normal Paint,galvanized ,etc|
|Application:||Food Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc||Surface:||Painted Finish, Galvanized Treatment,etc|
|Size:||Customized As Order||Wind Resistance:||25m/s ( Wind Scale 10)|
|Certification:||CE/ ISO 9001||Power Supply:||1-phase-220v, 3phase-380v|
Cantilever slide gate, may refer to any number of gates, from ornamental picket styles to functional chain link styles, from those that require cantilever rollers to those requiring gate tracks and trolleys. All cantilever slide gates will share certain characteristics which differentiate themselves from other types of slide gates. Cantilever slide gates are unique from other types of slide gates in their construction, hardware choices, and design.
Cantilever slide gates are built larger than the gate opening they are designed to close, often as much as 50% larger than their respective openings. The idea here is to hang the gate on two or more mounting posts and have the gate suspend off these mounting posts into the gate opening to close. In general, no part of the gate comes in contact with the ground directly, or indirectly with any type of wheel. Instead, these slide gates 'cantilever' to close the opening. Cantilever construction allows for overhanging structures without external bracing. It is key that cantilever gate frame be constructed properly to help withstand the forces of gravity and wind. Intricate diagonal bracing and trusses are usually strategically welded in place to help prevent gate sag.
|Item name||Cantilever Gates Smart Electric Sliding Doors Front Gates|
|Standard Height||1700mm (customized height available)|
|Color||Red Coated / (customized color)|
|Power Voltage||AC220V±20% 50Hz; AC110V±10% 60Hz|
|Power Consumption||250W — 370W|
|Working Temperature||-35°c — +70°c|
|Remote Control Distance||≤50m|
|Doorway Clear Length||4m — 8m|
|Moving mode||Suspension Sliding|
1.Whole packing for transportation or disassembling in package for small size and easy assembling without soldering
2.High-quality material, simple structure, excellent jointing, which make the gate elegant and grand
3.The gate is stable in suspension sliding without noise or friction or abrasion and be strong when closed.
4.Different colors optional to match with surround architecture
5.Anti-climb and anti-collision available for choice
1.The advanced microcomputer control technology will fully monitor the straight line sliding to assure of the best security in performance.
2.The high quality and technology motor is durable and easy to maintain. With the overheating protection device, the motor will stop working when the temperature is over 120 degree, and the best working temperature is from -35 to 70 degree.
3.Safety: with security device such as IR sensor, anti-collision and anti-clamp device, the gate will stop and return if any person crossing or obstacle happened during closing. With Emergency switcher, the gate can be stopped immediately to assure of security. With clutch device, the gate can be changed to be controlled by hand when the power is failed.
4.Be able to work in tough circumstances such as too high or too low temperature, wind, raining, ice, snow, uneven ground or some others.
5.No need pre-laid, easy installation and low failure rate.
Applied to school, enterprise, garden, stadium, government building, warehouse, front gates, industrial zone,etc.
