Lightweight Stainless Sliding Door Smart Access System With Insulation Door Panel

Product Details:

Place of Origin:	China
Brand Name:	FAMOUS
Certification:	CE,ISO9001,SASO,SGS
Model Number:	None

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD80-200 per Square meter
Packaging Details:	Standard seaworthy packing
Delivery Time:	15 days
Payment Terms:	L/C, T/T
Supply Ability:	1000 sets per month

Contact Now

Detailed Product Description

Door Frames:	Galvanized Steel , 304stainless Steel,etc	Type:	Hinged Doors, Sliding Doors,ETC
Color:	Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized	Surface Treatment:	Normal Paint,galvanized ,etc
Application:	Food Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc	Surface:	Painted Finish, Galvanized Treatment,etc
Size:	Customized As Order	Wind Resistance:	25m/s ( Wind Scale 10)
Certification:	CE/ ISO 9001	Power Supply:	1-phase-220v, 3phase-380v
Core Materials:	PVC Plastic Fabric

Lightweight Stainless Sliding Door Smart Access System With Insulation Door Panel

Description

Electric Heavy Industrial Sliding Doors are better for large openings and are custom built to meet the demands of our clients. They are ideal for industrial applications, both as indoor and outdoor doors where maximum door opening is needed. A wide selection of Industrial Heave Duty Overhead Sectional Steel Doors are available to satisfy applications where durability, reliability and economy are top priorities. An array of door panel profiles, track and hardware, and specialized options allows you to further customize these doors to your specific project requirements.

Size	6500mm(H)*8000mm(W),customized as order
Using location	Internal &External door
Insulation	Polyurethane foam
Thickness	50mm,70mm,100mm,120mm,etc.
Door Panel	polyurethane foam door panel or ALR type aluminum alloy frame inlaid PC endurance perspective door panel
Sealing system	aluminum alloy profile three ethylene propylene rubber bar top, bottom seal,rail steel auxiliary rail of three ethylene propylene rubber side seal, single door panel and the door is sealed between the sponge
Hardware accessories	track, auxiliary rail,roller,door side hinge wheel seat, the center hinge
Torsion spring balance system	galvanized rectangular tube middle beam; 60Si2MnA high quality spring steel torsion spring; torsion spring support bearing bracket, solid shaft coupling; torsion spring fixing seat, a torsion spring seat, wire wheels, wire rope.
Drive control system	drive motor, control box, remote control and so on
Safety protection device	steel wire rope break protection device; anti torsion spring break protection device; wireless safety air bag protection device; automatic protection device for preventing the top

Characteristics and Advantages

(1) Intelligent control design: adjustable main parameter and secondary parameter automatically according to the weight of door leaves;

(2) Low noise: Special static sound track, integration of motor, worm-gear and retarder.

(3) Anti-clamping function: automatically reverse when meeting barriers;

(4) Unique electronic motor lock: the motor will lock up when the door is forced to open.(controlled by remote or switch)

(5) Tighten force: seal door when closed, power consumption approximately 10W under standby;

(6) Advanced brushless motor(36V,100W) can automatically adopt different heavy door leaves;

(7) Bi-doors inter-locking: one of the door leaves always remains closing;

(7)Safety sensor terminal: sensor stops working when door closed;

(8)Unique coating technology: never rusty;

(9)Easy and convenient to install;

(10)Working Process: when the door leaf closes to the right place, the door leaf will slightly shift to the door frame and the ground. The rubbers on the four sides of the door leaf will completely combine with door frame and ground, which ensures air tightness. When the door is open, the rubbers will separate from door frame and ground, which avoids contraction on the ground.

Application :
