|Huafeng Road 2#, Xiacheng District, Hangzhou City, Zhejiang China||Tomy.Gao@hfsteelstructure.com||
|Place of Origin:||China|
|Minimum Order Quantity:||1 set|
|Price:||USD25-50 per Square meter|
|Packaging Details:||Standard seaworthy packing|
|Delivery Time:||15 days|
|Payment Terms:||L/C, T/T|
|Supply Ability:||1000 sets per month|
|Door Material:||Galvanized Steel , 304stainless Steel,etc||Core Material:||Steel Plate,Polyurethane Core Insulated Panel ,mineral Wool Panel,etc|
|Surface Sheet:||Galvanized Steel||Application:||Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc|
|Surface:||Painted Finish, Galvanized Treatment,etc||Size:||Customized As Order|
|Wind Resistance:||25m/s ( Wind Scale 10)||Certification:||CE/ ISO 9001|
|Power Supply:||1-phase-220v, 3phase-380v|
From the point of view of statics, steel profiled sections are the ideal choice for industrial door constructions. They can be used to construct rigid panels with a large surface area and slender frames. The same system of profiles can be used for folding doors, sliding doors and sliding folding doors. The various sections and weatherstrips are all suitable for manually or automatically operated door assemblies. Ingeniously designed central weatherstrips guarantee a high level of safety (no trapped fingers) and tightness.
|Product name||industrial folding door|
|material specifications:||Door frame: 50mm*80mm aluminum alloy special tube|
|Door leaf: Use built-in galvanized steel plate and concave-convex groove design, the panel adopts 0.8mm steel plate (can be sprayed)|
|Track: 50*50*3mm steel track, built-in ultra-high molecular insulation board, sealed with ti-propylene rubber strip|
|Hinge: aluminum alloy material|
|Portholes: 5mm toughened glass for self.|
|Door opener: each door is equipped with 2 sets of door openers. The door machine adopts the imported folding door special motor|
|control system:||The control box shall be guaranteed to be connected with fire control, which can be connected with the general control room for interlocking reaction|
Not only are the sizes of folding doors hugely diverse, but the doors are all completely made to measure and designed specifically for certain industrial, commercial (or even some domestic) applications. Alongside this, most of the doors can be fitted inside and outside the aperture.
Bi-folding doors provide various benefits. The doors are all insulated to keep in the heat, whilst they can often also be made using lots of glass elements.
Folding doors are incredibly easy to operate and can be opened only part of the way if needed. When fully opened however, the door folds into a small area, preventing obstuctions and preserving both internal and external space.
Folding doors have a numbr of configurations. There is due to the design, allowing either the whole door to fold away, or if you need quick and easy access a small pedestrian part of the door can fold on its own.
Folding doors can be automated if required and several doors have this option. Fast, reliable and quiet motors are available and showcase the best the market has to offer. A full range of controls are also available, including radio controls, key pads and even finger scanners.
Folding doors can be perfect for showrooms and shops when combined with large glazed panels. Manual operation is also easy to do, meaning that whilst automation is possible, they are one of the easiest door types to operate without such systems.
Easy installation and a wide range of accessories make these one of the most diverse and adaptable door types, perfect for countless different industries and uses.
Optional control system: Many access control systems are optional
Low noise: Specially designed noise-reduction track rail produces less noise, ensures the rollers to run smoothly
Various modes: Different triggering modes are available
Durable and Expeditious: Advanced brush less DC motor and the geared worm are integrated together, which has advantages such as higher efficiency, larger torque and longer life span, no need for mechanical lock.
Advanced level: The technology and materials used during design and manufacturing of the automatism are at the top of its category
Safe: Automatic Safety Protective Device: automatically rising up when being blocked
Certificate: CE & ISO & Appearance and utility patents
Surface is PVC fabric, double layer and beautiful.
Main skeleton is formed with steel tubes. It is designed through precise structure calculation with universal steel structure software, meeting requirements of wind resistance.
Safety Drop-proof device, can stop falling of door body when the steel wire of motor breaks suddenly, protecting human life under the door.
Multi-limit design guarantees precise running.
Inching control design makes sure there will always be a human operating the door when it runs. This can avoid accidents caused by human-absence.
High safety class of motor and steel wire, guarantees reliable operation.
Folding doors for factories and industrial units
Warehouse folding doors
Folding doors for aircraft hangars
Agricultural folding doors – barns, farms and stable partitions
Commercial folding doors – restaurants, shops, garages, schools, offices etc.
