|Huafeng Road 2#, Xiacheng District, Hangzhou City, Zhejiang China||Tomy.Gao@hfsteelstructure.com||
|Place of Origin:||China|
|Minimum Order Quantity:||1 set|
|Price:||USD80-200 per Square meter|
|Packaging Details:||Standard seaworthy packing|
|Delivery Time:||15 days|
|Payment Terms:||L/C, T/T|
|Supply Ability:||1000 sets per month|
|Door Frames:||Galvanized Steel , 304stainless Steel,etc||Type:||Lifting Door, High Speed Rising Door,etc|
|Color:||Blue,Yellow,Red,Grey,White,Full-clear,etc,Customized||Surface Treatment:||Normal Paint,galvanized ,etc|
|Application:||Food Factory, Pharmaceutical Factory, Warehouses, Packaging Industry, Chemical Industry, Etc||Surface:||Painted Finish, Galvanized Treatment,etc|
|Size:||Customized As Order||Wind Resistance:||25m/s ( Wind Scale 10)|
|Certification:||CE/ ISO 9001||Power Supply:||1-phase-220v, 3phase-380v|
|Core Materials:||PVC Plastic Fabric|
Quick Response Doors: the environment is also improved dramatically by controlling vehicle traffic flow, easing the vehicle access on the most used doors. With a working speed of up to 3-5 metres a second with some doors the operation cycle can be completed in a short time indeed, keeping the inside atmosphere as stable as possible. Access can be with remote control, readar sensors, ground loops, push button, key cards, digital code pads, finger readers and other devices all to suit your individual needs in the private garage or emergency situations.
The High speed automatic opening and closing of these rapid roll doors will provide valuable energy saving by maintaining the internal room temperature and also reduce contamination from airborne pollution and ingress of insects and vermin, essential in controlled warehouses and buildings.
All the high speed doors we supply meet the very highest levels of safety and are tested, CE/ISO 9001 approved and offer long term durability through some advanced technology and feature.
|High Speed Rolling Door|
|Size||6500mm( W)*8000mm( H),|
|Actual Size||Customized according to client's demands|
(frequency control system)
|opening 2.5m/s (adjustable); closing 1.8m/s (adjustable)|
|Material||coating galvanized steel; aluminum alloy; 304 stainless steel, food-grade , chemical proof ;|
|Color||Blue,Yellow,Red,Grey,White,etc based on customer's demands|
|Control Systerm||Domestic or Foreign motor brands ( PLC, transducer, switching power supply, breaker, etc.)|
|Motor(power supply)||380V (3phase)or 220V(1phase )/50HZ|
|Area of use||Indoor / outdoor|
|Security||1. Infrared ray induction system installed under the door frame
2. Pressure sensor installed under the curtain, and the falling door can
ascend automatically with 2 KGS pressure.
3. Can Install automatic derail system according to window pressure
4. Control system uses low voltage power
FASEC Doors offer a comprehensive range for high speed flexible roller and high speed insulated doors for internal and external installations. The High speed automatic opening and closing of these rapid roll doors will provide valuable energy saving by maintaining the internal room temperature and also reduce contamination from airborne pollution and ingress of insects and vermin, essential in controlled warehouses and buildings.
high speed doors are designed for fast open and close, allowing people and/or equipment to move quickly through the opening. This type of doors is ideal for large size opening and designed for high performance daily use both internally and externally with minimal maintenance. The door operated as speed > 1m/s, this model doors offers beneficial energy saving in both commercial and industrial application. In additional it reduces noise and dust from nearby working areas. It was ideally choice for many commercial and industrial application..
All the high speed doors we supply meet the very highest levels of safety and are tested, CE/ISO 9001 approved and offer long time durability through advanced technology & features. Welcome to visit our factory and hope to cooperate with you and your esteemed company in the near future!!!
