High Speed Full-View Metal Door With Polycarbonate Panels High Speed Aluminum Doors

High Speed Full-View Metal Door With Polycarbonate Panels High Speed Aluminum Doors

Description:

      High-speed doors are usually used wherever goods traffic occurs and where the doors have to fulfill special requirements. In the food and beverage industry, or Medical industry for example, special climatic conditions have to prevail; short opening and closing times reduce cooling loss, avoid airflow and enable a smooth operating procedure. They can also be designed in larger dimensions for the mining and aircraft industries.

TOPSKY Door high speed metal doors offer a high speed offering that is both secure and aesthetically pleasing with opening speeds up to 5-10M per second. High-speed doors are door systems, mainly used in industrial applications. They are technical enhancements of the generally known sectional doors, PVC fabric doors or roller shutters. The main difference is that the durable construction provides a higher operating speed and they are able to sustain a higher number of cycles (opening and closing cycles) and require lower maintenance and repair cost. Depending on the intended field of application, horizontal or vertical operating door types are available.

In North America, the Door and Access Systems Manufacturing Association (DASMA) defines high-performance doors as non-residential, powered doors, characterized by rolling, folding, sliding or swinging action, that are either high-cycle (minimum 100 cycles/day) or high-speed (minimum 20 inches(508 mm)/second), and two out of three of the following: made-to-order for exact size and custom features, designed to be able to withstand equipment impact (break-away if accidentally hit by vehicle) or designed to sustain heavy usage with minimal maintenance.

Specification:

Design Features

High Cycle Design:
Springless design for over 1 million cycles and requires minimal interruption for maintenance,
Gravity drive system coupled with variable frequency drive eliminates sudden jolts from door start/stop,
Direct-mounted gear drive minimizes wear and tear

Durable Construction:
Full-view door with corrosion-resistant aluminum and clear vision, impact-resistant polycarbonate panels,
Steel headplate utilizes high strength, durable rollers to prevent metal curtain contact and provides smooth operation,
Independently-tested and capable of withstanding pressure of up to +50/-50 psf and operating under pressures of up to +5/-5 psf.

Simple Install and Low Maintenance:
Fully-assembled curtain arrives pre-wrapped in headplate and trusses, ready for installation,
Completely hinged guide,
Pre-wired motor connection and plug and play accessories

Safety:
Patent-pending integrated curtain monitoring device ensures the door has a redundant system to monitor the position of the door
Safety light curtain minimizes contact with objects in the doorway
Monitored wireless reversing edge

Door Options
Slim guide available to reduce jamb side room
Multiple actuation options - push button, motion detector, radio control, key switch, pull switch, loop detector, treadle switch
Signaling devices - red/green LED warning light, horn/strobe combination, rotating warning light
Clear anodized slats/bottom bar
Lintel cover
Photo eyes

Applications:  Auto Dealerships, Retail, Manufacturing warehouse,plant buildings,etc.
